cording to recommendations from EHEDG and 3A, degree of protection IP 65/67
Accuracy ≤ 0.15 %
High-resolution graphic display with intuitive operation
and backlight
Quick access to device data
Comprehensive parameterisation, simulation and diag-
nostic functions
Nominal range 0.25 bar to 40 bar
Turndown up to 20:1
Output signal 4...20 mA with HART®-protocol
Digital communication via PDM/EDD and FDT/DT Output functions: linear, inverse
Table function with up to 32 support points
Wetted parts stainless steel
Case design:
- process connection at back
- process connection bottom
Various hygienic process connections, selected connec-
tions with EHEDG certificate
